Tested safety
for reliable protectionPut the advantages of this EN 12811-1 and DIN 4420 certified Service and Working Scaffold to work for you
- reduced costs, due to fast, safe working
- high load-bearing capacity (max. 600 kg/m²) means that wall formworks up to 5.50 m high can be stood on the platforms
- unobstructed, flat platform deck made possible by the retractable crane-hoisting points
- with practical add-on components for every usage situation
Rapid working
thanks to easy handlingReduced labour and crane times, thanks to
- pre-assembled units
- planning where to put the suspension points is easy, thanks to the system's logical concept
- ready for use straight away, after a very few quick and easy actions
Versatility
can be used for all types of safety taskDepending on your needs, you can use the pre-assembled scaffold platforms as
- working platforms
- protection platforms
- sloping-rooftop fall barriers
- protective canopies
Highly cost-efficient
saving you time and moneyAchieves cost-optimisation by
- being easy to use
- having a long lifespan
- not taking up much storage and transport space
References
System
- system consists of two straight platforms (3.00 m and 4.50 m long) and a corner solution
- two different suspension methods and a wide range of accessories for adapting to site requirements
- high load-bearing capacity of up to 600 kg/m² (= Scaffold Category 6)
- platform level can be raised / lowered by either 0.50 m or 1.00 m at a time
- long service life thanks to its sturdy design, varnished floor planking and galvanised steel construction
- planking protected by steel section on the narrowside
![folding platform k]()
![fold-away Folding platform K corner solution]()
The fold-away Folding platform K corner solution makes for safe, time-saving corner transitions without any trip hazards and loose decking boards.
Adding Handrail extensions K and safety netting turns the platform into a dependable sloping-rooftop fall barrier.
![Handrail extensions K and safety netting]()
Types of suspension points
The standard suspension point is prepared by screwing a suspension cone into an embedded positioning-point.
![standard suspension point]()
![loop-type suspension point with Bow head K-ES]()
To use the Folding platform K with loop-type suspension points, simply retrofit the platform with the Bow head K-ES.
A suspension plate can be used to retrofit a dependable suspension point to the concrete floor-slab whenever needed.
![suspension plate]()
![Fair-faced concrete positioning cone 15.0 5cm]()
The Fair-faced concrete positioning cone 15.0 5cm can be used to ensure that the form-tie points and suspension points produce a uniform hole-pattern.
Logistics
The Folding platforms K are pre-assembled and can be transported and stored folded closed. This saves space and keeps them safe from overturning and slipping. This high packing density translates into low shipping volume and excellent utilisation of the loading area of the truck.
![stack of Folding platforms K]()
